1. Key Technical Specifications
- Input voltage range: 48 VDC to 220 VDC (wide voltage range, adaptable to various grid conditions)
- Output voltage: 5 VDC and 24 VDC (standard industrial voltages)
- Output power: 85 W
- Rated current: 16 A
- Breaking capacity: 6 kA
- Number of poles: 3P
- Mounting method: DIN rail mounting
- Operating temperature range: –40°C to +85°C (suitable for harsh environments)
- Dimensions: Approx. 14.5 cm × 5.5 cm × 20.4 cm
- Weight: Approx. 0.666 kg
- Certifications: CE, UL, IECEx certified; protection class IP20
2. Functional Features
- High reliability: Built with industrial-grade components and designed to withstand vibration and dust, ensuring long-term stable operation.
- Redundancy support: Can be combined with other power supply modules (such as 560PSU01) to form a redundant power system, improving overall system fault tolerance.
- Modular design: Easy to maintain and replace, with support for hot swapping, facilitating on-site management.
3. Application Areas
- Power systems: SCADA, distribution automation, power plant monitoring.
- Industrial automation: PLC control, process control.
- Others: Traffic signaling, building automation, environmental monitoring.
